| d1
|
最小值=公称 |
| 最大值 |
| d2
|
最小值=公称 |
| 最大值 |
| H
|
最小值=公称 |
| 最大值 |
| D
|
公称 |
| 最大值 |
| 最小值 |
| L
|
最大值=公称 |
| 最小值 |
| a
|
| h
|
| r
|
| t1
|
| t6
|
|
| 3.8 |
4.9 |
5.8 |
6.9 |
9.2 |
11.6 |
14.1 |
16.3 |
18.7 |
21 |
23.4 |
| 3.92 |
5.02 |
5.92 |
7.05 |
9.35 |
11.78 |
14.28 |
16.48 |
18.91 |
21.21 |
23.61 |
| 2.8 |
3.7 |
4.7 |
5.7 |
7.6 |
9.6 |
11.6 |
13.6 |
15.6 |
17.5 |
19.5 |
| 2.9 |
3.82 |
4.82 |
5.82 |
7.75 |
9.75 |
11.78 |
13.78 |
15.78 |
17.68 |
19.71 |
| 7.8 |
9 |
8.3 |
9.2 |
12.3 |
15.5 |
14.9 |
16.2 |
18.7 |
22.2 |
24.8 |
| 7.95 |
9.15 |
8.45 |
9.35 |
12.48 |
15.68 |
15.08 |
16.38 |
18.91 |
22.41 |
25.01 |
| 16 |
16 |
20 |
20 |
28 |
32 |
32 |
38 |
38 |
48 |
48 |
| 16.066 |
16.066 |
20.08 |
20.08 |
28.088 |
32.107 |
32.107 |
38.107 |
38.107 |
48.12 |
48.12 |
| 16.039 |
16.039 |
20.047 |
20.047 |
28.055 |
32.068 |
32.068 |
38.068 |
38.068 |
48.081 |
48.081 |
| 18 |
18 |
24 |
24 |
34 |
38 |
38 |
45 |
45 |
58 |
58 |
| 17.93 |
17.93 |
23.916 |
23.916 |
33.9 |
37.9 |
37.9 |
44.9 |
44.9 |
57.88 |
57.88 |
| 7° |
7° |
7° |
7° |
7° |
7° |
9° |
9° |
9° |
9° |
9° |
| 0.5~1.0 |
0.5~1.0 |
0.5~1.0 |
0.5~1.0 |
0.5~1.0 |
0.5~1.0 |
0.5~1.0 |
0.5~1.0 |
0.5~1.0 |
0.5~1.0 |
0.5~1.0 |
| 0.6 |
0.8 |
1 |
1.2 |
1.6 |
2 |
2.4 |
2.8 |
3.2 |
3.6 |
4 |
| 0.04 |
0.04 |
0.05 |
0.05 |
0.05 |
0.06 |
0.06 |
0.06 |
0.06 |
0.06 |
0.06 |
| 0.025 |
0.025 |
0.025 |
0.03 |
0.03 |
0.04 |
0.04 |
0.04 |
0.04 |
0.05 |
0.05 |
|
